Overview
The Pool Fencing Latch is a high-performance magnetic latch system designed for secure and reliable pool fencing applications. Crafted from premium SS316 stainless steel, it offers exceptional durability and corrosion resistance, making it ideal for both indoor and outdoor installations.
Material: 316 Stainless Steel
Product Length: 3-7/8" (97.20mm)
Product Width: 3" (76.20mm)
Product Height: 2-3/8" (60.77mm)
Glass Thickness Range: 5/16" to 1/2" (8mm to 12mm)
Glass Type: Monolithic Tempered Glass
Glass Fabrication: 3/8" (10mm) Hole
Includes: Extra Glass Padding
Gasket: Black Interior Gaskets
Gasket Material: EPDM
Gasket Thickness: 1/16" (1.5mm)
Mounting Fastener Size: 1/4" Hole (Post Mounting), M8 Threaded (Glass Mounting)
Mounting Type: Wall Mount
Maximum Glass Width: 40"
Maximum Weight Capacity: 45 kg (100 lbs)
For technical inquiries: technical@ggh-usa.com
Product Warning: Always use appropriate safety equipment during installation. Improper installation may result in product failure or personal injury. Product images are for reference only; actual finish may vary.
| Length | 3-7/8 in. (97.20 mm) |
|---|---|
| Width | 3 in. (76.20 mm) |
| Height | 2-3/8 in. (60.77 mm) |
| Weight | 2.50 lbs. (1.1317 kg) |
