Overview
The GGH Cable Rail System - Fixed Cable End for wood posts is designed for secure and easy installations in wood railings. Made from durable AISI 316 stainless steel, it ensures high performance and long-lasting strength, making it perfect for outdoor and indoor use.
Material: 316 Stainless Steel
Cable Compatibility: 1/8" (3.2mm)
Dimensions:
L1 (Length 1): 1-11/16" (42.5mm)
L2 (Length 2): 1-21/32" (42mm)
D (Diameter): 7/16" (11mm)
T (Thread): ST8 Wood Screws Thread
Function: Provides a secure fixed anchoring point for cable termination in wood post railing systems
Compatibility: Cable, Stud, Curved Washer, Release Key, Cable Cutter, Tensioner
Application: Deck railings, patios, terraces, landscape railings, waterfront applications
| Length | 1-5/8 in. (42.00 mm) |
|---|---|
| Diameter | 7/16 in. (11.00 mm) |
| Weight | 0.04 lbs. (0.0200 kg) |
