The Core-Lock System Side Mount Base Shoe is engineered for frameless glass railing installations where floor space must remain unobstructed while maintaining a clean architectural appearance. Designed for side-mounted applications, this system utilizes an advanced wedge clamp mechanism that keeps the glass centered within the base shoe while allowing precise adjustment during installation. Suitable for residential and commercial projects, the system provides secure glass positioning, streamlined installation, and long-term performance.

More Product Information

Material: Aluminum 6063-T6 Base Shoe Extrusion

Product Length: 120" (3048mm)

Glass to Installation Wall Distance: 1-5/16" (33.55mm)
Glass Thickness Range: From 13/16" (20.26mm) to 7/8" (21.52mm) Glass
Glass Type: Monolithic Tempered Glass
Glass Fabrication Details: No Glass Holes Required

Includes: Base Shoe, Rubber gaskets, Core-Lock Wedge Clamp System, Flexibit Adjustment Tool
Clamp System: Metal and Plastic Wedge Clamp Assembly with Dual Adjustment Screws

Mounting Type: Side Mount

Adjustability: Dual-Screw Adjustment System
Tilt Adjustment: One adjustment screw is used for glass alignment and tilt adjustment
Glass Retention Adjustment: One adjustment screw is used to securely clamp the glass in position

Compatibility: Core-Lock System End Caps, Glass Railings and Related Installation Accessories

Application: Frameless Glass Railings, Balconies, Terraces, Deck Railings, Stair Railings, Commercial Guardrails, Residential Guardrails, and Architectural Glass Barrier Systems

For technical inquiries or quotes, please contact us at technical@ggh-usa.com.

Product Warning: Always use appropriate safety equipment during installation. Improper installation may result in product failure or personal injury. Product images are for reference only; actual finish may vary.
